With regards to the overall design of the pyrolysis plant, the reactor is largely an exceptionally important part. And it also was indeed the most important part for a lot of projects that were carried out across different energy industries. However, the primary measurements of the heating reactor was based mainly about the initial scale of the system. Continue reading since we dive further in to the design part of the pyrolysis reactor.
The reactor was created to be able to permit the maximum amount of raw materials to get fed to the machine. For this reason, a comparatively tiny amount of time was required for vapor residence inside the reactor. This will then lead to a pretty high yield value for the produced pyrolysis oil or rather liquid product.
In order to obtain the max from liquid production, the residence time is a vital factor with regards to working with both volatile gases and liquids alike. Hence the look was kept simple and easy a cylindrical shaped reactor was brought on stream. Additionally, the reactor is made from stainless because of how corrosive pyrolytic fluids actually are. As well as the reactor stood in a maximum height of 990 mm though it featured a 400 mm diameter. Get more details here: https://kingtigergroup.com/tyre-to-fuel-recycling-plant/.
The reactors feeder was that from the through type and yes it contained a 250 mm diameter and it was paid by a flat plate plus some nut-bolts. However, around the inner portion you'd find semi-hex pipes and three u-shaped spirals that seemed to experience a diameter of 19 mm. The very last length of the spiral pipes were 1370 mm along with the radius were roughly 76 mm. The pipes contained inside the reactor were simply used to make sure that faster heating was achieved.
In order to get rid of the charred bits, there seemed to be a 200 mm diameter throught in the reactors bottom. Additionally, there was another reactor shield that was constructed of thick 2 mm mild steel and its outer side was made from GP sheet which was also 2 mm. The final entire furnace was roughly 249 cm and also the reactors shield length was 60.96 cm by having an internal diameter of 4 cm.
However, the reactors shield is regarded as being one of the more important components and is comprised of 4 parts. As well as two turn out to be fixed while the other are portable. Additionally, the reactors shield contained glass wool that was used just for insulation. Together with the shield, there seemed to be additionally a burner which was useful for either gas or oil.
To have proper firing, you'll require a proper burner. Not to mention, this can be used to ensure the optimum temperature is achieved for operations. Hence two burners were designed and set up on either side of your furnace. And they even allowed fuel and air to circulate into the furnace during pyrolysis.
When we conclude we have now just checked out the entire design of the waste tire recycling plant reactor. And that we have even discussed two major components of the reactor. So, take into account that your reactor dimension is fully dependant on your overall system size!
